Lighttells CM-100 Plus Coffee Roast Degree Uniformity Ground-Size Analyzer

The Lighttells CM-100 Plus Coffee Roast Analyzer allows you to categorize the degree of roasting between whole bean and ground, providing a deeper understanding of the roasting process and final outcome. Its purpose is to enhance quality control for coffee roasting vendors, coffee shop owners, and dedicated home roasters. With its fast key functionality, precise measurements, extended operational hours (up to 6 continuous hours), and convenient portability and storage, the CM-100 Plus guarantees optimal performance.

• Ideal analyzer kit for coffee roasters, coffee labs, coffee shops, and home roasters
• NIR photometer tells the caramelization from the coffee beans or ground
• Roast degree measuring range: 5-130
• Reads in both SCAA and Agtron scale
• One-touch quick measuring key
• An infrared photometer reads the caramelization from the coffee beans or grounds
• Stores up to 200 measurement results
• Supports SCAA scale
• Can be used while charging
• Auto-power off setting
• Supports measurements result from output to PC

• Display 1.6” 128 x 64 mono
• OLED Working hours: 6
• Warm-up time: 1 minute
• Display: 2.6 inch 128 x 64 OLED panel size
• Light: Infra-red LED
• Sensor: Infra-red Sensor
• Battery: Li-ion 1150 mAh Battery
• Working Temp: 0-45C
• Dimensions: 123.4mm / 4.86in x 123.4mm / 4.86in x 132mm / 5.20in
• Weight: 230g / 8.11oz
• AC adapter: 110 - 240V, 50/60Hz
• Charging input: 5V, 2A
• Certification: CE, FCC (every two years)
• Panel Color: Red
• Housing Color: Black
• Housing material: ABS and Aluminium
• Charging Method: MicroUSB Port
• Log Output: micro USB Cable

All new Lighttells products include a 1-year parts warranty.
