Modbar Steam Under-Counter Station

The Modbar Steam delivers a minimal, modern aesthetic coupled with power and control. Recreate a traditional espresso machine with two Steam systems next to your Modbar Espresso, or set up distinct service areas to suit your workflow. Give your customers a full view of their drink being prepared, from espresso pull to latte art.

• Double-walled, pro-touch wand
• Chromed tap
• Ergonomic handle designed to match Espresso AV
• Custom handle finishes walnut (standard) or maple
• Omnidirectional ball fitting
• Minimal purge required with no steam valve rebuilds
• Linea-style porthole boiler sight glass
• Simple on/off switch controlled by solenoid in the module
• Right-hand side connections for easy service access

Dimensions:

• Tap: 3.5”(W) x 12.5”(H) x 11.25”(D)
• Module: 17”(W) x 8.5”(H) x 15”(D)

Weight:

• Tap: 7.7 lbs
• Module: 40 lbs

Module Capacity: 4.6L (Dual Boiler)

Volts: 208V - 240V

Amps: 14.4 (ETL) / 13 (CE)

Element Wattage: 3310 (ETL) / 2705 (CE)

Frequency: 50/60hz

Certifications: ETL, CE

• Modbar Steam Above-Counter Tap
• Modbar Steam Below-Counter Module
• Two Steam Tips
• Drip Tray

The Modbar Steam includes a standard 13 months parts-only warranty from the original date of shipment.

• Installation Guide
• Product Brochure
